Honeywell’s PX940 Series Label Printers for Error-Free Printing

Distribution businesses require reliable and durable industrial printers. The Honeywell PX940 series takes industrial printing to a new level of precision and simplicity by providing customers with error-free precision printing, increasing productivity and reducing operating costs. The PX940 industrial printer provides customers with 100% readable and printable barcodes, predictive analytics and a lower total cost of ownership through integrated label verification technology and operational intelligence software.

You can expect extremely accurate printing up to /-0.2 mm (0.0079 in), virtually eliminating poor quality, unreadable labels and barcodes. The Smart Print feature allows end users to configure settings without the need for a host computer. ANSI technology immediately informs you of the status and status verification of each passing device. The device is easy to use and maintain, with a color multilingual touchscreen interface and a quick side-mounted design.

The PX940 printer is ideal for transportation and logistics, pharmaceutical and healthcare, transportation and distribution centers, industrial manufacturing, automotive parts suppliers, and applications that require high-accuracy and error-free printing.

PX940 Printer Features & Advantages

• ► Integrated label verification technology checks to ensure labels print accurately every time; notifies you of pass/fail status and ANSI ratings of labels in a timely manner.
• ► The printing accuracy can reach ±0.2mm, which can exclude poor printing quality, unreadable labels and barcodes.
• ► Provides predictive analytics and data on printer health, helping managers monitor entire printer fleets and proactively prevent issues to maximize uptime.
• ► The configuration of the printer can be done on the printer through the Smart Print function without relying on the host computer.
• ► Easy to use and maintain, color multi-language touch screen interface, quick side-mounted consumables.

This product verifies labels against pass/fail criteria and ANSI International Standards (1 to 4), rejecting and reprinting bad labels that do not meet established thresholds. The printing accuracy is as high as ±0.2mm, which can achieve accurate printing on small labels, and respond to the current market trend of label miniaturization.

PX940 printers are widely used in electronics manufacturing, automotive manufacturing, large-scale transportation logistics, pharmaceuticals, shipping and distribution centers, and applications that require strict regulation, high precision and error-free printing. Models are available with or without an integrated validator. Both models come standard with Bluetooth® connectivity, smart printing, and more, allowing users to configure and fine-tune settings without the need for a host computer.

The PX940 printer is based on the Honeywell firmware platform that supports multiple printing languages ​​and can easily replace similar competitors. Its rugged all-metal construction, easy-to-replace printheads, and tool-less removal rubber rollers minimize downtime and maintenance needs. Supports a wide variety of media, including inner and outer carbon ribbons with a core size of 1 inch, maximizing media replenishment time. Fast label editing and print speeds of up to 350 mm/s (14ips) allow it to scale with changing and dynamic operational needs.

PX940 Series Specifications

Standard parameters

• Printing Methods: Thermal Transfer and Thermal Printing
• 3.5-inch color touch liquid crystal display (LCD)
• Foldable clear media door
• Dual label stop sensor for accurate printing
• Dual-core 1 GB processor (ARM® Cortex® A9 processor)
• 256 MB Flash
• 1 GB DDR3 SDRAM
• Multi-GB USB storage device (FAT16/FAT32)
• Built-in real-time clock

Mechanical parameters

• PX940A/PX940V (with validator model)
• L x H x W: 506 mm x 398.7 mm x 261 mm (19.92 inches x
• 15.70″ x 10.28″)
• Weight: 23 kg (50.71 lbs)
• PX940A:
• Weight: 23 kg (50.71 lbs)
• PX940V (with validator model):
• Weight: 23.5 kg (51.81 lbs)

Print Specifications

Print Resolution:

• 203 dpi: 8 dots/mm
• At 300 dpi: 11.8 dots/mm
• 600dpi: 23.6 dots/mm

Print Speed:

• At 203 dpi: 50 – 350 mm/s (2–14 ips)
• At 300 dpi: 50 – 300 mm/s (2–12 ips)
• At 600 dpi: 25-150mm/s(1-6 ips)

Maximum width:

• 203 dpi: 108 mm (4.25 inches)
• At 300 dpi: 105.7 mm (4.16 inches)
• At 600dpi: 105.6mm(4.16 inches)

Maximum continuous print length:

• 203 dpi: 4.8 m (15.75 ft)
• At 300 dpi: 2.2 m (7.22 ft)
• 600dpi: 0.55m (1.81 inches)

Barcode Verifier Specifications

(PX940 Verifier Version)

Scanning resolution: 600 dpi

Maximum scan width: 108 mm (4.25 inches)

Light source: 660 nm

The fastest verification speed: 100 mm/s (4 ips)

Barcode orientation: horizontal or vertical

Barcode Verification Mode: Linear (1D) barcodes in accordance with ISO/IEC 15146-2016

Verification; Verification of two-dimensional (2D) barcodes according to ISO/IEC 15415-2011; Read

Take/not read barcode verification

Minimum linear (1D) barcode width: 10 mils (0.254 mm)

Minimum 2D cell size: 15 mils (0.381 mm)

Supported symbols: Code 39, HIBC 39, Code 128, ISBT 128, HIBC

128, EAN 8, EAN 13, EAN 128, UPC A, UPC E, Crossover 2/5

Code, ITF 14, Data Matrix and ISBT Data Matrix

Maximum verification length: 304.8 mm (12 inches)

Maximum invalid print length: 152.4 mm (6 inches)

Maximum number of verifiable barcodes per label: 32

Minimum medium opacity: 80%

Maximum working ambient light: 5000 lux

Verification Report: Access the printer web page to view statistics and detailed reports.

Software

Printer command language: Fingerprint (FP), Direct Protocol

(DP), IPL, ZSim2 (ZPL-II), DPL; for SAP® AII and Oracle®

WMS enables XML

Application/Driver: InterDriver Windows® Printer Driver

And one-click driver installation, CUPS driver for Linux, Honey for SAP

Vill device types, and Honeywell label design and printing packages

Smart Printing print language:

Honeywell C# language for printers: Smart Printing

Developer Resource Kit; written using a .NET compatible development environment

Program without validator function

Configuration and device management support:

Printset supports Windows, Android and iOS versions for configuring printers
; a mature web interface for configuration, upgrade and one-to-one management

Media Specifications

Media types: non-continuous label stock, black mark stock, tag stock, perforated stock, notched stock

or continuous label paper

Max/Min width (label and pad): 114/20 mm (4.5/0.79 inches)

Minimum tag length:

Tear off mode: 3.0 mm (0.12 inches)

Self-peeling mode: 12.7 mm (0.5 inches)

Rewind mode: 6.0 mm (0.24 inches)

Thickness (label and liner): 3 mil – 10 mil

Configuration: Outer Roll or Folded Paper

Maximum roll diameter: 212.7 mm (8.375 inches)

Label Core: 76 mm (3 inches)

Ribbon Specifications

Ribbon support: inner carbon or outer carbon

Maximum roll diameter: 80 mm (3.15 inches), approximately 450 m (1,476 feet)

Core ID: 25 mm (1 inch)

Max/Min width (ribbon and core): 110/51 mm (4.33/2.0 inches)

Types: Wax-based, Hybrid-based and Resin-based

Authentic Honeywell Media: www.honeywellaidc.com/media

Interface

Standard:

USB 2.0 host interface (x2)

USB 2.0 device interface

Ethernet interface, transmission rate 10/100 Mbps

RS-232, transfer rate up to 115.2 KB/s Bluetooth

Multiple print languages ​​supported:

Fingerprint/Direct Protocol: XON/XOFF,

ENQ/ACK, DSR/DTR, RTS/CTS

IPL: XON/XOFF, Honeywell Std. Protocol

User interface language:

Color digital LCD screen and web interface: English, Italian, French, Spanish

Tooth, Portuguese, German, Russian, Traditional Chinese, Simplified Chinese, Korean, Japanese

Chinese and Thai

Power

PFC power supply with rated power of 200W

AC voltage: 100V AC to 240V AC, 47Hz to 63Hz

Working environment

Operating temperature: +5°C … +40°C (+41°F … +104°F)

Storage temperature:

PX940A: -20°C … +70°C (-4°F … +158°F)

PX940V (with validator model): -20°C … +60°C (-4°F …

+140°F)

Humidity: 20% … 85%, no condensation

Options and Accessories

Verifier Calibration Card

(PX940 model with authenticator only)

Parallel interface card

Wireless Network Interface Card

Labeling machine interface card

Industrial GPIO and serial interface cards

Peeling and rewinding assembly (factory option)

Barcode/Font/Graphics

Barcode Symbology: Supports all major 1D and 2D symbols

Supported standards: UPC/EAN Shipping Container, UCC/EAN 128

, Serial Shipping Container, MH10.8 Shipping Label, AIAG

(shipping parts label), OGMARS, POSTNET, HIBCC, ISBT

128, GM1724, UPS Shipping Label and Global Transport

Label

Font: Monotype font engine; supports non-Latin fonts via WTLE,

Customers can also download (Truetype) fonts themselves.

Graphics: PCX, PNG, GIF and BMP file formats are supported. Other formats are available

Supported by Label Generation Tools.

Regulatory Certification

RoHS Compliance, CE (EN55032 Class A), FCC Class A, Energy Compliant

Star 2.0 Standard
